Soundproof
In our designing process, we fully utilize acoustic simulation software such as INSUL MARSHALL ACOUSTIC to iterate and obtain optimal acoustic performance.
Our booth is consistent with the standard of environmental rating Design value: Rw+Ctr 25 db (+5 db) and RT0.75 s (+0.1 s).
Lighting
Equipped with 4000 K daylight color temperature LED lighting system (150 LX), it would satisfy the needs of normal activities. In the event of additional power requirements, a backup power supply is readily installed inside the booth.
Soundproof glass
The silence booth utilizes the same type of noise-reducing glass found on high-speed trains.
Acoustic Interior
Our booth has an effective area of 60% covered Polyester Fiber sound absorbing material.
Optional furniture
We can recommend what type of aesthetic and acoustic furniture is optimal for your Silence Booth.
Motion Sensor
Soundbox Silence Booth is equipped with motion sensor to control the lighting and ventilation system.
220V Power
Our booth is equipped with 12V-USB power supply and power rated for 100-240V/50-60Hz.
External cable hole
An external opening allows cables to easily pass into the booth. The opening may be closed when not in use.
4 different sizes to meet your needs
Model:
S
Exterior size:
D936 x W1000 x H2300mm
(36.85″ x 39.37″ x 90.55″)
Inner size:
D900 x W840 x H2140
(35.43″ x 33.07″ x 84.25″)
Capacity:
For one person
Model:
M
Exterior size:
D1236 x W1500 x H2300mm
(48.66″ x 59.06″ x 90.55″)
Inner size:
D1200 x W1340 x H2140mm
(47.24″ x 52.76″ x 84.25″)
Capacity:
For two person
Model:
L
Exterior size:
D1536 x W2200 x H2300mm
(60.47″ x 86.61″ x 90.55″)
Inner size:
D1500 x W2040 x H2140mm
(59.06″ x 80.31″ x 84.25″)
Capacity:
For four person
Model:
XL
Exterior size:
D2136 x W2200 x H2300mm
(84.09″ x 86.61″ x 90.55″)
Inner size:
D2100 x W2040 x H2140mm
(82.68″ x 80.31″ x 84.25″)
Capacity:
For six person
